24 Zone Nurse Call Panel – Audio-Call Alarm System

The 24 Zone Panel is a centralized monitoring and alarm panel designed to supervise multiple zones within a Medical Gas Pipeline System (MGPS). It enables healthcare and engineering personnel to monitor the status of medical gas supplies across up to 24 designated zones or monitoring points, depending on the system configuration.

The panel provides visual and audible alarm indications when monitored parameters move outside configured limits, supporting rapid identification of medical gas pipeline issues in hospitals and other healthcare facilities.

Key Features

• Supports monitoring of up to 24 zones
• Centralized medical gas pipeline monitoring
• Audio and visual alarm indications
• Clear zone-by-zone status display
• High/low pressure monitoring, depending on configuration
• Easy identification of affected zones
• Suitable for continuous hospital monitoring
• Wall-mounted panel design
• Compatible with appropriate pressure sensors/transducers
• Suitable for large healthcare facilities and multi-department installations

Common Applications

• Hospital Medical Gas Pipeline Systems (MGPS)
• Operating theatre complexes
• Intensive Care Units (ICU)
• High Dependency Units (HDU)
• Emergency departments
• Maternity and neonatal units
• Hospital wards
• Recovery rooms
• Medical gas plant rooms
• Multi-floor and multi-department medical gas installations

Product Specifications

Product Name: 24 Zone Panel

Type: Medical Gas Zone Monitoring / Alarm Panel

Capacity: Up to 24 Zones

Display: Visual Status Indicators / Digital Display, model dependent

Alarm: Audible & Visual

Mounting: Wall Mounted, model dependent

Monitoring: Pressure / System Status, configuration dependent

Application: Medical Gas Pipeline Systems (MGPS)

Installation: Hospital & Healthcare Facilities
